LPG and natural gas infrared chicken coop heater used in winter
1.Specifications
Now based on IR catalytic techlonogy,we manufacture gas brooder for poultry house,greenhouse and others,with two ways to ignition:manual ignition(THD2606) and auto ignition type(THD2608).
| Model | N.W | Dimension | Gas Consumption | Heat Output |
| | kg | mm | NG | LPG | Biogas | kw/h | kcal/h |
| Manual Ignition Type Heater |
| THD2606 | 1.7 | out cover 320*270*130 ceramic plate 188*135 | 0.24 m3/h | 0.18 kg/h | 0.5 m3/h | 2.46 | 2116 |
| Electric Ignition Type Heater |
| THD2608 | 2.7 | out cover 320*270*130 ceramic plate 188*135 | 0.24 m3/h | 0.18 kg/h | | 2.46 | 2116 |
| Electric Pulse Igniter | 220V AC/50HZ or 110V AC/60HZ |
| Ignition Pin | 3-pin type |
| Solenoid Valve | 220V AC/50HZ or 110V AC/60HZ |
1).Detail photos:THD2606 Manual Ignition Type with adjust valve.
2).Detail photos:THD2608 automatic electric ignition type.
2.Material
Shell:Heat resisting aluminized steel imported from Korea.
Inner ceramic plates:Cordierite honeycomb plate with catalytic coating(gray color).
Safe switch:copper flame out protection device on THD2606,automatic ignition stystem for THD2608.
3.Advantages
1).Energy saving can be as high as 20% per year.
2).Environment protection:CO≤80ppm,NOx≤10ppm,CHx≤50ppm.
3).THD2608 could keep the room constant temperature automatically when use thermostat.
4).It can cut off the gas automatic and protect the burner when the flameout.
5).THD2606 could adjust big and small fire.
6).Easy to be clean and fixed.
7).long usefull time:≥11000 hours.
8).Silent,light and compact when it is working.
4.Application
Poultry livestock heating:widely used in poultry heating,farrowing,nursery,grower-finisher,wean-to-finish,greenhouse etc.
5.Packing and delivery
